Marine Application

Products & Solution

Customized Solutions

BENDIG™ marine AHU application offers total customization of standard systems to meet specific customer needs for marine air conditioning and marine Climate control technology. Spare parts are available for the entire range of BENDIG marine application to ensure prompt service.

Extensive Product Range

BENDIG™ marine AHU offers a wide selection of energy efficient marine heating and cooling solutions that include Chilled water, packaged air-cooled, Energy recovery and beyond any requirement complying with all relevant marine certification requirements.

Durability

Anti-corrosion treatment is provided for installation in harsh environmental conditions.

AHU+Energy Recovery

We divide our energy recovery concept
into 2 sections

1. AHU+ for Energy recovery
2. AHU+ for Dehumidification

AHU + for Energy recovery

Reclaiming heat from exhaust air and returning it to the fresh supply stream reduces energy consumption in a huge range of buildings such as hospitals, swimming pools, supermarkets, schools and colleges, restaurants, and social clubs. In every case, the running cost of the energy recovery system is virtually nil, and maintenance is minimal

AHU+ for Dehumidification

Pre cooled and Reheated in AHU enhances the performance of a dehumidifier and improves the quality of the recycled air. The energy recovery provides a more comfortable environment for living and working in applications such as shopping malls, call centres, supermarkets for example. The improvements in efficiency come without any increased running costs from the heat pipe.

ERV-Heat Pipe

ERV-PHE

ERV-Rotor

ERV-Run-around Coil

Low humidity AHU (Dessicant Packaged AHU)

BENDIG™ Desiccant Packaged Air Handling Unit (DP-AHU) are intended for mass transfer of water vapor for use in desiccant dehumidification and desiccant cooling equipment. For use in this broad range of applications, BENDIG has been engineered for maximum durability under operating condition serve.

Features:

Space saving
Low humidity control (Below 35%RH or Lower 6C Dew-point)
Double skin casing cabinet
None combustion casing insulation
Controller system complete set from factory
Energy recovery regeneration

Hygienic-Air Handling Unit

Benefit of HAHU

The HAHU Certification sets new industry standard for the following reasons.
1. Easy to classified: Create 1 to 3 star rating that accounts for different hygienic requirements.
2. Proven hygienic performance: Stringent, annual factory and selection software audits.
3. One certification: Eurovent HAHU combines the requirements of multiple hygienic standard (e.g. VDI6022-1,DIN1946-4,HTM) in single programe – bringing an end to international standard of requirement.

Introduction

BENDIG™ has been participating in the Eurovent Certiﬁcation program since 2012. The certiﬁcation body has recently, extend their program coverage to hygienic design prospect of air handling units. BENDIG has been develped its ptp-h range to full ﬁll broader requirement for units serving in public area, cleanroom, and healthcare facility. Our ptp-h range is now Eurovent Hygienic certiﬁed with 3 stars rating. The highest rating suitable fr the most hygiene requires.

The air handling unit deﬁnition:

A factory-made encased assembly consisting of a fan or fans and other necessary equipment to perform one or more of the functions of circulating, cleaning, heating, cooling, humidifying, dehumidifying and mixing of air.

The hygienic air handling unit deﬁnition:

The air handling unit where suitable for using in the sensitive sterile condition.

Hygienic Air Handling Unit

AHU Definition:

A factory made encased assembly or flat-packaged unit that consists of a fan or fans and other necessary equipment to perform one or more of the following functions: circulating, filtration, heating, cooling, heat recovery, humidifying, dehumidifying and mixing of air. The unit should be suitable to be used with ductwork.

H-AHU Definition: “The air handling unit where used in the sensitive sterile conditions.”

Benefits of PTP-H (Metallic Part)
Physical AHU shall be specific Hygienic-Characteristic

Compare Hygienic Certification

BENDIG™ provide water based antimicrobial surface to our AHU. It contains both a bactericide to protect the coating against over 650 strains of bacteria and a fungicide to protect against mold, mildew and algae. Bioshield technology inhibits reproduction, interrupts metabolism and disrupts cell wall functions of many molds, yeasts and bacteria. This hygienic technic be applied to plant in our equipment surface for instance , walls, frame-works and other appropriate surfaces to reduce microbiological contamination and propagation.

For the physical configuration BENDIGTM also studies the detail of Hygienic requirement regarding to standards and/or design consideration follow as below.

Explosion Proof AHU

Maximize safety for Atmospheric Explosion

In explosive atmosphere or delivering explosive air are special requirements which have to be definitely and proven observed by operator, planner, constructor and manufacturer. We are inexperienced both world-class design-consideration for Explosion-proof, ATEX requirement and IEC-Ex

Selection of certified components, setup and assembly by especially trained experts, individual approval and inspection of each unit as well as check and supervision by Third-parties provide highest safety to our clients.

Weatherproof Application

All accessories and non-metalic materials made from UV-resistant material for last-long operation

Roofing

We provide metalic material as our standard, GI, Aluminium, SUS304 and SUS316, 316L. Non-metalic material, we can provide polyester as per optional
